Sizes: ½” to 2”
Connections: Screwed BSPT Female. Outlet one size larger than inlet
Pressure Range: 0.2 to 24.0 bar (up to 14.0 barg for steam)
Working Temperature: -60°C to +200°C
Test Lever: Open Lever Lift
Body: Bronze
Seat: Brass
Seal: PTFE
Spring: Stainless Steel
WRAS Approved.
Designed in accordance with BS EN ISO 4126-1:2013.
P.E.D 2014/68/EU.
